Baldor D5007P 7.5 HP 1750/2300 RPM SHUNT WOUND 218AT Frame WE CRATE & SHIP INTL

THIS IS A WAREHOUSE REMODEL LIQUIDATION OF SPARE PARTS. THIS UNIT HAS NOT BEEN USED IT IS NEW ON THE SHELF BEING LIQUIDATED TO MAKE ROOM FOR REMODEL.

BEING SOLD AT HALF MSRP OVER $22,000 MSRP AT MOTION INDUSTRIES

THIS UNIT WILL SHIP FREIGHT YOU CAN SEE DETAILS BELOW
WE CAN SHIP INTERNATIONAL. PLEASE ASK FOR AN ACCURATE QUOTE
WE CAN SHIP TO MANY INTERNATIONAL AREAS EVEN BY AIR VERY AFFORDABLY.
SAMPLE RATE OF A 350 lb item US to Germany was $463.00 VIA AIR
SAMPLE RATE OF 700lb item US to England was $770.00 VIA AIR

BELOW IS INFORMATION PER SPECS FROM MANUFACTURER WEBSITE PORTRAYED AS ACCURATLY AS POSSIBLE HOWEVER WE ARE POSTING INFORMATION COPY AND PASTED( PLEASE ENSURE BY LOOKING AT TAGS ON PHOTOS ITEM MATCHES YOUR NEEDS)


The Baldor-Reliance D5007P is a 7.5 HP, 1750 / 2300 RPM DC motor. It belongs to the Baldor-ABB Motors Shunt Wound SCR Series and is engineered for precise speed and constant torque industrial applications.
Technical Specifications

* Motor Type: Shunt-wound, brushed DC motor.
* Frame Size: NEMA 218AT.
* Voltage Ratings: 500 V Armature / 150/300 V Field.
* Current Draw: 13.2 A Armature / 0.69 A Field.
* Enclosure: DPFG (Drip-Proof Fully Guarded), self-ventilated.
* Shaft Diameter: 1.375 inches (1-3/8") with standard pulley-end extension.
* Mounting: Rigid base, F1 layout.
* Insulation: Class F.

Performance Characteristics & Components

* Constant Pressure Springs: Built with constant pressure brush springs to minimize ongoing maintenance and ensure even brush wear.
* Low Inertia Armature: Designed with a low inertia armature to allow for rapid, crisp response times during operation.
* Thermal Protection: Features an integrated thermostat on the interpole for high-limit temperature safety.
* Tachometer Adaptable: Ready to accept tachometer integration for advanced feedback loops.
* Pulley Application: Ideal for high-torque belt-and-pulley operations such as plastic extruders, heavy conveyors, and packaging machinery.

The Baldor-Reliance Catalog No. 10142 is a small 0.17 HP (approximately 1/8 HP), 3450 RPM AC industrial induction motor built for three-phase power systems. According to the manufacturer data sheets from Baldor-ABB, it features a compact, totally enclosed design suited for continuous commercial or industrial duty.
Technical Specifications

* Horsepower: 0.17 HP
* Synchronous Speed: 3600 RPM (nominal) / 3450 RPM at full 60Hz load
* Electrical Phase: 3-Phase (3 PH)
* Frequency: Dual-rated for 50 Hz (2850 RPM) and 60 Hz (3450 RPM)
* Voltage Ratings: 208-230/460 Volts AC
* Full Load Amperage: 0.66-0.60 A (at 208-230V) / 0.30 A (at 460V)
* Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
* Frame Size: NEMA 42C (C-Face mounting without standard base rigid legs)
* Shaft Diameter: 0.375 inches (3/8")
* Motor Design / Type: Design B, Type 3313M
* Service Factor: 1.00

Why Are These Two Motors Attached?
Industrial DC motors like the Baldor D5007P generate substantial internal heat when run continuously at low speeds or under high-torque loads. Because the motor's built-in shaft fan slows down alongside the armature, it cannot provide enough airflow to cool itself at low RPMs.
To solve this, engineers bolt a small, independent AC motor-like the Baldor 10142-onto the main frame's ventilation inlet. This small 3450 RPM motor runs at a constant high speed, pushing a steady stream of top-tier cooling air through the big DC motor regardless of how slow the main 7.5 HP shaft is turning. This layout transforms the assembly from a standard DPFG (Drip-Proof Fully Guarded) motor into a Blower-Ventilated (DPFV) system, maximizing its operating lifespan.
